Belanger SpinLite - Motor;Gearbox, Drive Shaft & Cover Assembly

SpinLite® Full Side Washer
1MANUL961 Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 87
Maintenance
Exploded Parts View
Motor/Gearbox, Drive Shaft & Cover Assembly
108661
9723
1FSTNR-HH045 (3)
1BERNG849
1PLSTC-CV077
1FSTNR-FH075 (8)
7912
7918
1PLSTC-CV080
1COLLR333
1FSTNR-SM502
110708
1WASHR-LC125 (3)
1STEEL–KY150
10366
1PLSTC-CV077
1PLSTC-CV080
Complete Assembly: 110720
1FSTNR-SM502 (2)
9724
1WASHR-FL747 (2)
1RETNR129 (2)
9725 & 1FSTNR-PH108 (2)
10366
See Enlarged
View Above
1COLLAR333
7203 (2) & 1WASHR-LC581 (2)
1FSTNR-HH714 (2) &
1WASHR-LC581 (2)
112271: 208/230V
112272: 575V
See
Above
See image on right
for part numbers
1DECAL-SL010
See Right
Note:
The part numbers shown for the Motor/Gearbox,
Drive Shaft & Cover Assembly are the same for
both Driver and Passenger Side SpinLite® Full
Side Washer.
