SpinLite® Full Side Washer
1MANUL961 Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 91
Maintenance
Exploded Parts View
ShineMitt™ 19” 45 Degree Short Lead: 111060 (Qty. 80)
The pair of SpinLite® FSW assemblies require a total of 80 pieces
of 111060 ShineMitt™ Cleaning Material. The ShineMitt™ fingers
on the driver and passenger side SpinLite® FSW assemblies face
in opposite directions and the head of the Pin must face downward
when loaded onto Hubs. So, 40 pieces of the ShineMitt™ must be
assembled as shown in the image above for the driver side FSW.
And, 40 pieces must be assembled as shown in the image below
for the passenger side FSW.
