Belanger SpinLite - Arm Assembly: Pivot Shaft & Bumper Assemblies; Arm Assembly: Bearing & Electrical Cable Assemblies

SpinLite® Full Side Washer
1MANUL961 Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 84
Maintenance
Exploded Parts View
Arm Assembly: Pivot Shaft & Bumper Assemblies
Arm Assembly: Bearing & Electrical Cable Assemblies
Driver Side:
Silver PC:
111990
Aluminum: 111679
Passenger Side:
Silver PC:
111991
Aluminum: 111680
9714 (2)
1WASHR-FL185 (4)
1SPRNG242 (2)
Black PC: 108205
Aluminum:
108066
1ELECT-FS220 (2)
(Length: 8.33 IN)
1FSTNR-HH585 (2)
1FSTNR-HH522 (4)
1WASHR-LC456 (6)
7960 (2)
1FSTNR-SH725 (2)
1FSTNR-SH090 (4)
Note:
The part numbers shown for the Pivot Shaft and
Bumper Assemblies are the same for both Driver
and Passenger Side SpinLite® Full Side Washer
except where specified.
1WASHR-FL747 (2)
1RETNR129 (2)
1FSTNR-HH714 (2)
7203 (2)
1WASHR-LC581 (4)
1BERNG849
1BERNG849
1WASHR-LC581 (4)
1FSTNR-HH714 (4)
1ELECT-FS230 (5.125 IN)
1ELECT-FS231
1FSTNR-HH288
Driver Side:
Silver PC:
Aluminum: 111679
Passenger Side:
Silver PC:
Aluminum: 111680
1WASHR-LC291
1WASHR-FL498
Black PC: 10620
Aluminum: 10368
9644
24VDC Cable: 110716
4 Pin Supply Cable
Length: 81 IN
Cable: 1ELECT-CB874
16GA / 4 Conductor
Length: 6FT
See Enlarged
Image Below
Note:
The part numbers shown for the Bearing and
Electrical Cables Assemblies are the same for both
Driver and Passenger Side SpinLite® Full Side
Washer except where specified.
