51Bend-Tech Dragon A400
Maintenance & Troubleshooting
Miscellaneous
13
13
Miscellaneous
Ethernet Connections
Ensure there is a direct connection between the Ethernet port on the Control Box and the
Computer.
Y
A B
Z
X
Y C X
-
B A+ A-
EStop
Engraver Torch
Laser
Gate EStop EStop
Z
+ Z-
L
E
Router
WiFi*
PC Tower
(Back)
Control Box
*Computers provided by Bend-Tech
have a built in WiFi adapter. However, if
WiFi is not available the computer will
need to be connected to the internet
with a USB to Ethernet adapter.
To Next Page
