Bender ISOMETER IRDH575 User Manual

Technical data IRDH575
109
IRDH575_D00089_05_M_XXEN/01.2020
Status number
Value of the respective number
Position of numbers from the left
0 = 1 = 2 = 3 = 4 =
1
K1: N/O operation Test K1: N/C operation Test K1: flashing function K1: N/O operation K1: N/C operation
2
K2: N/O operation Test K2: N/C operation Test K2: flashing function K2: N/O operation K2: N/C operation
3
no external coupling
4
Cemax 1 µF ** Cemax 10 µF ** Cemax 150 µF Cemax 500 µF
5 6
Self test every 24 hours Self test every hour no periodic self test
7
Language German Language English
8
Password protection not
activated
Password protection
activated
9
AMP measuring
principle
DC measuring principle
10
max. filter frequency
0.1Hz **
max. filter frequency 1Hz
**
max. filter frequency
10Hz **
max. filter frequency
50Hz **
11
min. filter frequency
0,1Hz **
min. filter frequency 1Hz
**
min. filter frequency
10Hz **
min. filter frequency
50Hz **
12
BMS mode ** Isodata ** test data **
13
Bus address in the tens
place IRDH575
Value: 5 ... 9
14
Bus address in the units
place IRDH575
Value: 5 ... 9
15
Number of pulses 2-9 **
Value: 5 ... 9
** The parameters marked with two asterisks are settable via the Service menu item! A password is required for that
purpose !
