Technical data IRDH575
96
IRDH575_D00089_05_M_XXEN/01.2020
9.3 Characteristic curves
9.3.1 Characteristic curves of the ISOMETER®
ISOMETER® response times in relation to system leakage capaci-
tances of:
C
e
= 1…500 µF
U
n
= 20…575 V (Version B1) / 50 Hz
U
n
= 340…760 V (Version B2) / 50 Hz
1
10
100
1000
1 10 100 1000
C
e
[µF]
≤ 10 MΩ
≥
0 kΩ
R
F
t
an
[s]
