9.3.2 Characteristic curves of the insulation fault locators
EDS46… /EDS49…
Allowable response values for AC systems
Allowable response values for 3AC systems
0
10
20
30
40
50
60
70
80
90
100
24 48 110 230 400
U
n
[V]
R
F
[kΩ]
2 mA
5 mA
10 mA
0
50
100
150
200
250
24 48 110 230 400 500 690
U
n
[V]
R
F
[kΩ]
2 mA
5 mA
10 mA
