53 Bender Operation Manual
Bender Operation Manual 53
BENDING TOOLING
1 5R-212 2-1/2” / 63.5mm 5” / 127mm Radius Die
1 5R-214 2-1/4” / 57mm 5” / 127mm Radius Die
1 5R-200 2” / 50.8mm 5” / 127mm Radius Die
1 4R-214 2-1/4” / 57mm 4” / 102mm Radius Die
1 4R-200 2” / 50.8 mm 4” / 102mm Radius Die
1 35R-134 1-3/4” / 44.5mm 3-1/2” / 89 mm Radius Die
1 35R-112 1-1/2” / 38mm 3-1/2” / 89 mm Radius Die
2 BS-212 2-1/2” / 63.5mm Back Shoes
2 BS-214 2-1/4” / 57mm Back Shoes
2 BS-200 2” / 50.8mm Back Shoes
2 BS-134 1-3/4” / 44.5mm Back Shoes
2 BS-112 1-1/2” / 38mm Back Shoes
1 HS-212 2-1/2” / 63.5mm Half Shoe
1 HS-214 2-1/4” / 57mm Half Shoe
1 HS-200 2” / 50.8mm Half Shoe
1 HS-134 1-3/4” / 44.5mm Half Shoe
1 HS-112 1-1/2” / 38mm Half Shoe
SWAGER TOOLING
1 STED-212 2-1/2” / 63.5mm Solid Expander Die / 2-1/4” Male Ball Expander
1 STED-214 2-1/4” / 57mm Solid Expander Die / 2” Male Ball Expander
1 STED-200 2” / 50.8mm Solid Expander Die / 1-3/4” Male Ball Expander
1 STED-134 1-3/4” / 44.5mm Solid Expander Die
1 STED-112 1-1/2” / 38mm Solid Expander Die
1 HAC-212 2-1/2” / 63.5mm Hinged Adapter Collar
1 HAC-214 2-1/4” / 57mm Hinged Adapter Collar
1 HAC-200 2” / 50.8mm Hinged Adapter Collar
1 HAC-134 1-3/4” / 44.5mm Hinged Adapter Collar
1 HAC-112 1-1/2” / 38mm Hinged Adapter Collar
1 HPF-300 One Tool Fits All Sizes 45 Degree / 90 Degree Flaring Tool
1 DD-134/212 One Tool Fits All Sizes Doming Die
1 BFED-134/214 1-3/4” & 2-1/4” Female Ball Flaring Tool
1 BFED-200-212 2” & 2-1/2” Female Ball Flaring Tool
1 B-212 2-1/2” / 63.5mm Male Ball Tool
SEGMENT EXPANDER TOOLING
1 HSA-112 One Size Fits All Sizes Arbor
1 SS-212 2-1/2” / 63.5mm Segment Expander
1 SS-214 2-1/4” / 57mm Segment Expander
1 SS-200 2” / 50.8mm Segment Expander
1 SS-134 1-3/4” / 44.5mm Segment Expander
1 SS-112 1-1/2” / 38mm Segment Expander
ACCESSORIES
1 TTA-1000 Tool Tray Kit
2 DPS-150 Radius Die Pusher Block Springs
1 Manual Service Manual
1 OR-1 Small O-Ring Package
Other Sizes Are Available Upon Request
ECONOMY 2O2 DIE PACKAGE
QTY. PART NO. SIZE TOOLING DESCRIPTION
