PL-6000DC/DCX Two-Post Parking Lift 10 P/N 5900273 — Rev. A6 —July 2024
Specifications
Model PL-6000DC PL-6000DCX
Lifting capacity per Platform
6,000 lbs. (2,700 kg) 6,000 lbs. (2,700 kg)
a Total width, outside edge to
outside edge
100.25 in. (2,547mm) 112 in. (2,847 mm)
b Lift Platform Length
157 in. (3,990 mm)
c Post height; *See note 1
131 in. (3,320 mm)
d Post, center to center width
93.75 in. (2,382 mm) 105.5 in. (2,682 mm)
e Post Support Length
60.25 in. (1,532 mm)
f Lifting height
82.5 in. (2,100 mm)
g Control Column Height
71 in. (1,805 mm)
h Lift Platform (Usable Width)
82.5 in. (2,100 mm) 94.5 in. (2,400 mm)
i Side Clearance min.
2 in. (50.75 mm)
j Platform to Support
36.25 in. (918.25 mm)
k Length Overall
163.5 in. (4,152.5 mm)
Lifting Time
<50 Seconds
Motor
208-240V, 50/60HZ, 1-Ph., 4 HP, 22 Amps
Operating Temperature and
Humidity
+41° to +104°F / +5° to +40°C 50% RH
*Note 1. Balance Chain adjustment adds up to 2.25 in. (57 mm) above the Post height.
