PL-6000DC/DCX Two-Post Parking Lift 82 P/N 5900273 — Rev. A6 —July 2024
Parts Drawings
Item P/N Description Qty.
1 5530304 HHB M8 x 1.25 x 20mm 4
1 5545340 WASHER; M8 x OD-24mm FLAT 4
2 5530025 HHB M8 x 1.25 x 12mm 4
2 5545340 WASHER; M8 x OD-24mm FLAT 4
3 5530304 HHB M8 x 1.25 x 20mm 34
3 5535052 M8 Flanged Nut with Serration 34
4 5530304 HHB M8 x 1.25 x 20mm 48
4 5535052 M8 Flanged Nut with serration 48
5 5530738 HHB M10 x 1.5 x 25mm 2
5 5535053 M10 x 1.5 Flanged Nut with serration 2
