PL-6000DC/DCX Two-Post Parking Lift 83 P/N 5900273 — Rev. A6 —July 2024
Item P/N Description Qty.
1 thru 4 5530107 HHB M14 x 2.0 x 40mm 4
1 thru 4 5545349 WASHER M14 SL 4
1 thru 4 5545015 WASHER; M14 FLAT 4
1 thru 4 5403361 NUT; M14 x 2.0 4
5 thru 6 5530107 HHB M14 x 2.0 x 40mm 2
5 thru 6 5545349 WASHER M14 SL 2
5 thru 6 5545015 WASHER; M14 FLAT 2
5 thru 6 5403361 NUT; M14 x 2.0 2
To Next Page
