PL-6000DC/DCX Two-Post Parking Lift 52 P/N 5900273 — Rev. A6 —July 2024
Connect To Power
Connect the Power Unit to an appropriate Power Source through the Power Disconnect Switch.
Power for this Lift is 220 VAC, 60 Hz. single phase and should be protected by an appropriately rated
fuse or circuit breaker.
Refer to the Wiring Diagram and Control Panel Wiring Diagram for further information.
⚠ DANGER All wiring must be performed by a licensed Electrician in accordance with all
applicable national and local electrical codes. Do not perform any maintenance or
installation on the Lift without first verifying that main electrical power has been
disconnected from the Lift and cannot be re-energized until all procedures are
complete.
⚠ WARNING Keep Wiring and Hydraulic Hoses away from sharp edges or pinch points to avoid
damage.
Important Electrical Information:
• Improper electrical installation can damage the Power Unit Motor. This damage is not covered
under warranty.
• Use a separate Circuit Breaker for each Lift Installed.
• Protect each circuit with an appropriate time-delay fuse or circuit breaker.
To connect the Lift to Power:
Verify the Power is disconnected and locked out to prevent re-energizing while you work on the
Lift.
Connect the Main Power Supply wiring to the Power Disconnect Switch just installed using an
appropriate gauge wire for the voltage, current and length of run.
Route the Power wiring from the Power Disconnect up to the Junction Box on the Power Unit.
Refer to the Wiring Diagram and Control Panel Wiring Diagram to connect the power to
the Contactor and Thermal Disconnect, the Solenoid, and Control Panel in the Junction Box.
Wire the Power Unit Junction Box
The Junction Box houses the wiring and connections for Power, Thermal Overload (if required), Limit
Switch, Solenoid and the Lift Controls.The Controls on the Console allow the operator to raise and
lower Vehicles. Refer to the figure above and the Wiring Diagram and Control Panel Wiring
Diagram for wiring information.
⚠ DANGER All wiring must be performed by a licensed, certified Electrician in accordance with
all applicable national and local electrical codes.
The Junction Box wiring includes:
• Power. Wiring connections for power supplied to the Hydraulic Power Unit from the Power
Disconnect Switch.
• Control Panel. This wiring includes the Up, Down and Emergency Stop Lift functions.
• Limit Switch. This Switch stops the upward motion of the Lift Platform.
• Solenoid. The Solenoid opens the Hydraulic Valve allowing the Lift Platform to Lower.
