PL-6000DC/DCX Two-Post Parking Lift 59 P/N 5900273 — Rev. A6 —July 2024
To Raise a Vehicle, Pre-Lifting Stage
Review the Operating Manual and all safety labels before using the Lift.
Inspect the Lift before use. If worn, broken or missing parts are found, do not use. Take the Lift
out of service.
Drive the Vehicle onto the Lift Platform. The Vehicle should be centered on the Platform, and may
be driven in nose first or backed in.
Drive until the Vehicle’s tires rest against the Back Stop.
Place the Vehicle’s gear selector in park, turn off the engine, and engage the safety brake. For
Manual Transmissions shift to first gear, turn off the Engine and set the Safety Brake.
Check the front of the Lift to verify the Vehicle’s tires are securely on the Platform.
Walk around the Lift to ensure there are no obstructions that could interfere with the Vehicle being
lifted.
Position yourself in front of the Operator’s Control Panel.
To raise a Vehicle – Lifting Stage:
Once all the precautions above are followed, check around and above the Lift to ensure that no
objects are obstructing the Platform, and that no persons (except the Lift operator) are within 10-
feet / 3 meters.
To raise the Lift Platform to the desired height, turn the Key Switch on the Control Panel to the
left (counterclockwise) and hold.
Always raise the Lift Platform until it reaches its top Limit Switch position.
If a low ceiling is overhead, be cautious as you lift the Vehicle. Never allow the top of the Vehicle to
come into contact with any overhead structure or object.
Once the top position is reached, release the Key Switch to its neutral position.
