Measured values of test procedures Class I (VDE 0701-0702)
AUTO
test no.
Name
Individual tests
1
Devices of Class I
RPE (600 mA), RInsu-1 (500 V), functional test with IPE (differential current measurement)
2
Devices of Class I with RPE 10 A
RPE (10 A), RInsu-1 (500 V), functional test with IPE (diff.)
3
Devices of Class I with ICont dir.
RPE (600 mA), RInsu-1 (500 V), ICont (dir.), functional test with IPE (diff.)
4
Devices of Class I without RPE +
ICont dir.
RInsu-1 (500 V), ICont (dir.), functional test with IPE (diff.)
5
Devices of Class I
heating < 3.5 kW
RPE (600 mA), RInsu-1 (500 V, R ≥ 0.3 MΩ), functional test with IPE (diff.),
for testing heating devices with P < 3.5 kW
6
Devices of Class I with IPE alt.
RPE (600 mA), RInsu-1 (500 V), IPE (alt.)
7
Devices of Class I RPE 10 A +
IPE alt.
RPE (10 A), RInsu-1 (500 V), IPE (alt.), for testing extension cables up to 5 m or tools with
300 Hz such as power screwdrivers, grinding tools,...
8
Devices of Class I with RInsu
250 V
RPE (600 mA), RInsu-1 (250 V), functional test with IPE (diff.),
for testing devices with overvoltage arresters
9
Devices of Class I without RInsu
RPE (600 mA), functional test with IPE (diff.),
test procedure without RInsu only with factual basis and justification
10
Devices of Class I without RInsu
+ ICont dir.
RPE (600 mA), ICont (dir.), functional test with IPE (diff.),
test procedure without RInsu only with factual basis and justification
11
Devices of Class I with U output
RPE (600 mA), RInsu-1 (500 V), RInsu-2 (500 V), RInsu-3 (500 V), ICont (dir.), functional
test with IPE (diff.), Ua at the secondary output (max. 25 V),
e. g. for testing mains supply units and chargers
12
Devices of Class I with IPE clamp
RPE (600 mA) and RInsu-1 (500 V) with BENNING CM 9 and adapter (part no.:
044127/ 044128), IPE (clamp measurement), three-phase devices via adapter
(part no.: 044122/ 044123)
13
Devices of Class I RPE 10 A
with IPE clamp
RPE (10 A) and RInsu-1 (500 V) with BENNING CM 9 and adapter (part no.:
044127/ 044128), IPE (clamp measurement), three-phase devices via adapter
(part no.: 044122/ 044123)
14
Shock-proof cable with probe
RPE (600 mA), RInsu-1 (500 V), for line tests of shock-proof cables up to 10 A
15
Shock-proof cable with probe
RInsu 250 V
RPE (600 mA), RInsu-1 (250 V), cable (line length 5 m/ line cross-section 1.5 mm²/ number of
conductors = 3/ resistance value per line 0.3 Ω, for line tests of shock-proof cables up to 16 A
16
Shock-proof cable without probe
RInsu-1 (500 V), cable (line length 5 m/ line cross-section 1.5 mm²/ number of conductors = 3/
resistance value per line 0.3 Ω, for line tests of shock-proof cables up to 16 A
17
Devices of Class I, three-phase
RPE (600 mA), RInsu-1 (500 V), functional test three-phase with IPE (diff./ dir.)
18
Devices of Class I RPE 10 A,
three-phase
RPE (10 A), RInsu-1 (500 V), functional test three-phase with IPE (diff./ dir.)
19
Power distributor RCD type A
RPE (600 mA), RInsu-IN (500 V), RInsu-OUT (500 V), IPE (diff.), RCD type A (30 mA)
20
Power distributor RCD type B
RPE (600 mA), RInsu-IN (500 V), RInsu-OUT (500 V), IPE (diff.), RCD type B (30 mA)
21
CEE extension adapter
RPE (600 mA), RInsu-1 (500 V), functional test (continuity, short-circuit, rotary field)
22
CEE devices of Class I with IPE
alt.
RPE (600 mA), RInsu-1 (500 V), IPE (alt.)
23
PRCD-S
RPE (600 mA), RInsu-IN (500 V), RInsu-OUT (500 V), IPE (diff.), ICont (dir.), PRCD-S
(30 mA)
24
PRCD-S+
RPE (600 mA), RInsu-OUT (500 V), IPE (diff.), ICont (dir.), PRCD-S+ (30 mA)
25
PRCD-K
RInsu-IN (500 V), RInsu-OUT (500 V), IPE (diff.), PRCD-K (30 mA)
26
PRCD-AC
RPE (600 mA), RInsu-IN (500 V), RInsu-OUT (500 V), IPE (diff.), PRCD-AC (30 mA)
27
PRCD-A
RPE (600 mA), RInsu-IN (500 V), RInsu-OUT (500 V), IPE (diff.), PRCD-A (30 mA)
28
PRCD-F
RPE (600 mA), RInsu-IN (500 V), RInsu-OUT (500 V), IPE (diff.), PRCD-F (30 mA)
29
PRCD-B
RPE (600 mA), RInsu-IN (500 V), RInsu-OUT (500 V), IPE (diff.), PRCD-B (30 mA)
30
PRCD-B+
RPE (600 mA), RInsu-IN (500 V), RInsu-OUT (500 V), IPE (diff.), PRCD-B+ (30 mA)
31
PRCD 2-pin
RPE (600 mA), RInsu-IN (500 V), RInsu-OUT (500 V), IPE (diff.), PRCD 2-pin (30 mA)
32
PRCD 3-pin
RInsu-IN (500 V), RInsu-OUT (500 V), IPE (diff.), PRCD 3-pin (30 mA)
