91
27.2 Factory settings, setup of limits
RPE tests
RPE VDE 0701-0702
0.3
RPE VDE 0751-1
0.3
RPE VD 0544-4
0.3
The following applies to all RPE tests:
RPE ≤ 0.3 Ω, admissible for protective conductors with a length
of up to 5 m
0.1 Ω (max. up to 1.0 Ω) are added to each additional lien length
of 7.5 m.
RPE values are preset for a line cross-section of 1.5 mm².
RInsu tests
RInsu-1 VDE 0701-0702, Class I, LN-PE
1.00
MΩ
RInsu-1 VDE 0701-0702, Class II LN-test body
2.00
MΩ
RInsu-1 VDE 0701-0702, Class III, input-test body
0.25
MΩ
RInsu-1 VDE 0751-1, Class I, LN-PE
2.00
MΩ
RInsu-1 VDE 0751-1, Class II, LN-test body
7.00
MΩ
RInsu-1 VDE 0544-4, Class I, LN-PE
2.50
MΩ
RInsu-1 VDE 0544-4, Class II, LN-test body
5.00
MΩ
RInsu-2 VDE 0701-0702, Class I, secondary-PE
0.25
MΩ
RInsu-2 VDE 0701-0702, Class II, secondary-test
body
0.25
MΩ
RInsu-2 VDE 0701-0702, Class III, output-test body
0.25
MΩ
RInsu-2 VDE 0751-1, Class I, secondary-PE
70.00
MΩ
RInsu-2 VDE 0751-1, Class II, secondary-test body
70.00
MΩ
RInsu-2 VDE 0544-4, Class I, secondary-PE
2.50
MΩ
RInsu-2 VDE 0544-4, Class II, secondary-test body
2.50
MΩ
RInsu-3 VDE 0701-0702, Class I, LN-secondary
2.00
MΩ
RInsu-3 VDE 0701-0702, Class II, LN-secondary
2.00
MΩ
RInsu-3 VDE 0701-0702, Class III, input-output
0.25
MΩ
RInsu-3 VDE 0751-1, Class I, LN-secondary, type B
2.00
MΩ
RInsu-3 VDE 0751-1, Class I, LN-secondary, type BF
70.00
MΩ
RInsu-3 VDE 0751-1, Class I, LN-secondary, type CF
70.00
MΩ
RInsu-3 VDE 0751-1, Class II, LN-secondary, type B
7.00
MΩ
RInsu-3 VDE 0751-1, Class II, LN-secondary, type BF
70.00
MΩ
RInsu-3 VDE 0751-1, Class II, LN-secondary, type CF
70.00
MΩ
RInsu-3 VDE 0544-4, Class I, LN-secondary
5.00
MΩ
RInsu-3 VDE 0544-4, Class II, LN-secondary
5.00
MΩ
RInsu-4 VDE 0701-0702, Class I, LN-access. parts
without PE
2.00
MΩ
RInsu-4 VDE 0751-1, Class I, LN-access. parts
without PE
7.00
MΩ
RInsu-4 VDE 0544-4, Class I, LN-access. parts
without PE
5.00
MΩ
The following applies to all RInsu measurements:
Testing voltage LN/ input PE/ test body
500
V
Testing voltage secondary/ output PE/ test body
250
V
Testing voltage LN/ input secondary/ output
500
V
IPE tests
IPE VDE 0701-0702, devices in general
3.5
mA
IPE VDE 0701-0702, with heating elements
> 3.5 kW
1.0
(max.
10 mA)
mA/ kW
IPE VDE 0544-4, Class I
10.0
mA
ICont tests
ICont VDE 0701-0702
0.5
mA
ICont VDE 0544-4
0.5
mA
ICont VDE 0544-4 welding output
10.0
mA
ILeak tests
ILeak VDE 0751-1, Class I
0.5
mA
ILeak VDE 0751-1, Class II
0.1
mA
IPLeak tests
IPLeak VDE 0751-1, Class I, AC, type BF
5.00
mA
IPLeak VDE 0751-1, Class I, AC, type CF
0.05
mA
IPLeak VDE 0751-1, Class I, DC, type BF
0.01
mA
IPLeak VDE 0751-1, Class I, DC, type CF
0.01
mA
IPLeak VDE 0751-1, Class II, AC, type BF
5.00
mA
IPLeak VDE 0751-1, Class II, AC, type CF
0.05
mA
IPLeak VDE 0751-1, Class II, DC, type BF
0.01
mA
IPLeak VDE 0751-1, Class II, DC, type CF
0.01
mA
Cable test
Line length
5.0
m
Line cross-section
1.5
(stated
in
[mm²])
No. of conductors
3
Resistance per conductor
0.3
Ua/ Ua weld. (output voltage)
Ua VDE 0701-0702, max. output voltage
25.0
V
Ua weld. VDE 0544-4, max. output voltage AC
0.0
V
Ua weld. VDE 0544-4, max. output voltage DC
80.0
V
Ua weld. VDE 0544-4, max. peak value
113.0
V
PRCD-AC
Tripping current I nom.
30
mA
Tripping time 1 x I nom.
300
ms
Tripping time 5 x I nom.
40
ms
Tripping time ½ x I nom.
300
ms
Max. contact voltage:
25
V
PRCD-A and F
Tripping current I nom.
42
mA
Tripping time 1 x I nom.
300
ms
Tripping time 5 x I nom.
40
ms
Max. contact voltage:
35
V
PRCD-B and B+
Tripping current I nom.
60
mA
Tripping time 1 x I nom.
300
ms
Tripping time 5 x I nom.
40
ms
Max. contact voltage:
50
V
PRCD 2-pin/ 3-pin/ K/ S and S+
Tripping current I nom.
30
mA
Tripping time 1 x I nom.
300
ms
Tripping time 5 x I nom.
40
ms
Max. contact voltage:
25
V
Test times
All test times of individual tests for the automatic
test procedures are set by default as follows:
5
s
Delay time for mains pole reversal
The default delay time is:
0
ms
