18.2 Test procedures according to VDE 0751-1
Test procedure overview Class I/ Class II
AUTO test no.
Class I
Class II
1
2
3
4
5
1
2
Name
Med. devices of Class
I
Med. devices of Class
I without RInsu
Med. devices of Class
I type
BF
Med. devices of Class
I type
CF
Med. devices of Class
I type
B
Med. devices of Class
II
Med. devices of Class
II without RInsu
Visual inspection
X
X
X
X
X
X
X
Connection test
X
X
X
X
X
X
X
RPE 600 mA
X
X
X
X
X
RInsu-1/
RInsu-IN
X
X
X
X
X
RInsu-2
X
X
X
RInsu-3
X
X
X
ILeak
X
X
X
IPLeak
X
X
X
Functional test
X
X
X
X
X
X
X
Measured values of test procedures Class I (VDE 0751-1)
AUTO
test no.
Name
Individual tests
1
Med. devices of Class I
RPE (600 mA), RInsu-1 (500 V), functional test with ILeak (diff.)
2
Med. devices of Class I without
RInsu
RPE (600 mA), functional test with ILeak (diff.)
3
Med. devices of Class I type BF
RPE (600 mA), RInsu-1 (500 V), RInsu-2 (250 V), RInsu-3 (500 V), ILeak (diff.),
IPLeak (alt., type BF), functional test with ILeak (diff.)
4
Med. devices of Class I type CF
RPE (600 mA), RInsu-1 (500 V), RInsu-2 (250 V), RInsu-3 (500 V), ILeak (diff.),
IPLeak (alt., type CF), functional test with ILeak (diff.)
5
Med. devices of Class I type B
RPE (600 mA), RInsu-1 (500 V), RInsu-2 (250 V), RInsu-3 (500 V), ILeak (diff.),
IPLeak (alt., type B), functional test with ILeak (dir.)
Measured values of test procedures Class II (VDE 0751-1)
AUTO
test no.
Name
Individual tests
1
Med. devices of Class II
RInsu-1 (500 V), functional test with ILeak (diff.)
2
Med. devices of Class II without
RInsu
Functional test with ILeak (diff.)
