27 Technical data
Mains connection:
230 V  10 %
50-60 Hz
Current consumption of
appliance tester:
without test socket
with test socket
0.3 A
16.0 A
Maximum current load of
the test socket:
16.0 A
(load type, see following tables)
Maximum pre-fuse:
16.0 A
Protection class:
(as the protective conductor for the test
socket is looped through)
II
Protection category:
IP 40 with the cover being
open
IP 67 with the cover being
closed
Overvoltage category:
II
Contamination level:
2
Touchscreen dimensions:
115 mm x 87 mm
Ambient conditions:
Altitudes of up to 2000 m
above sea level
Temperature range:
Operating temperature
Storage temperature
0.0 °C to 35.0 °C
-20.0 °C to 60.0 °C
Max. relative humidity:
linearly decreasing
non-condensing
80.0 % at 30.0 °C
60.0 % at 40.0 °C
Specified accuracy for
operating temperature
range:
18.0 °C to 28.0 °C
EMC:
DIN EN 61557-16:2015-12,
EN 61326-2-2
Housing:
Carrying case, shock-
resistant and impact-proof
Device regulations:
See chapter 28.
Dimensions (max.):
Height x width x depth
(170 x 410 x 350) mm
Weight:
~6 kg
Tripping type of PRCDs:
PRCD type
Tripping
type
AC
AC
A
half-wave
B
DC
B
DC
2-pin
AC
3-pin
AC
F
half-wave
K
AC
S
AC
S+
AC
Note:
The measuring accuracy is calculated as the sum of a relative part
of the measured value.
This measuring accuracy applies to temperatures from 18 °C to
28 °C and a relative air humidity lower than 80 %.
27.1 Technical data, measuring and device function
DIN EN 61557-16:2015-12:
The tester must allow the measurement of at least the following
parameters:
 protective conductor resistance
 insulating resistance
 protective conductor current
(direct current, differential current or alternative leakage current
method)
 contact current
(direct current, differential current or alternative leakage current
method)
The application standards VDE 0701-0702, VDE 0751-1 and
VDE 0544-4 use different terms for the same measuring methods
depending on the properties and intended use of the parts. Thus,
the following terms are used for leakage currents:
device leakage current, earth leakage current, protective
conductor current, contact current, patient leakage current etc.
The measuring data logging works with three measuring ranges
(1:1, 10:1, 100:1). Switch-over of the measuring range occurs
automatically, so that measurement is always carried out in the
most favorable measuring range.
Connections:
 separate 4 mm test sockets and IEC connector
 4 x USB interface (type A), 1 x USB interface (Mini B)
 1 x SD card slot
 1 x RJ45
Max. storage capacity of the storage media:
 SDHC card max. 32.0 GB
 USB stick max. 32.0 GB (FAT32 file system)
Factory settings, system data:
 Test time: 5.0 sec.
Safety shutdown:
 Time: 30.0 sec.
Transition resistance:
 connector 5.0 Ω
