Benning ST 760 - Creating; Searching a Test Sample - Database Administration; Barcode Reader Specification

79
Creating/ searching a test sample – database
administration
 Navigate from the main menu to the “Settings”
screen.
 Navigate to the "Database administration"
screen.
 Select or create a database.
 Select or create a customer.
 Select or create a department.
(not mandatory).
Creating a test sample
Searching a test sample
 Touch the “ID no.” or
“Designation” line on the
left of the screen.
 Touch the “ID no” line on the
right of the screen.
 Tap the “New” button.
The “Device ID” screen
opens.
The “ID no.” screen opens.
 Stick a barcode label on the
test sample and scan the
barcode using the barcode
reader.
 Scan the already existing
barcode using the barcode
reader.
The scanned barcode is
automatically applied and
confirmed.
The test sample is applied as
the current selection.
The “Device” screen opens.
 Complete the data of the
test sample according to
chapter 0.
 Tap the “Save” button.
The test sample will be
created.
You will get back to the “Database administration” screen.
20.4 Barcode reader specification
USB barcode reader
Supported barcodes
UPC/EAN/JAN & add-on 2/5, Code 39, Code 39 Full ASCII,
Interleave 25, Industrial 25, Matrix 25, Code 11, Code 128,
Codabar/NW7, Code 93, MSI/PLESSEY, Code 32, BC 412,
China Postage
Operating voltage, current consumption
5 V DC; 100 mA
Scanning angle
supported:
± 65° to the vertical axis
not supported:
exactly 90° to the barcode
Scanning distance
2.5 mm to 600 mm
Operating temperature
0 °C to 50 °C
Storage temperature
-40 °C to 70 °C
Air humidity
5 % to 95 %
relative air humidity
non-condensing
