15
Attaching the Host to a ceiling mount
If the display is mounted on the ceiling:
1. Attach the Host to the ceiling mount using the provided velcro strap.
2. Fix the Host to the mounting holder.
3. Use the supplied velcro to x the mounting holder and the Host to the ceiling mount as shown
in the illustration.
• Please only use the velcro strap (300(L)mm*25(W)mm) provided with the kit to mount the Host to a ceiling
mount.
• Please see Positioning the Host antennas on page 18 for guidelines on positioning the antenna to maximize
signal reception.
Placing the Host on a table
If your display is placed on a table, rst attach the lid of to the Host in the following the process
described below:
1. Align the lid over the bottom of Host so that the triangle on the bottom side of the lid is aligned
to the triangle in the lid compartment, then insert the lid into the lid compartment.
2. Turn the lid counter-clockwise until it clicks into place.
