Reference 49
English
Supported HDMI input signal resolutions
• Resolutions outside of these tables are not recognized and will not be
displayed.
• When you connect the TV to a PC, you should adjust the resolution in the
display properties of the computer to closely match the native resolution of the
TV (for example, 1360 x 768 pixels).
• To view the best quality picture when using the PC input, you will then need to
instruct the TV to calibrate itself to the PC signal timing. To do so, select 'Auto'
in the 'Picture' menu. See "Auto Adjust" on page 35.
Setting up appropriate output resolution on PC
Before connecting the TV to a PC to display PC video, please follow the
instructions below (in Windows XP for example) to setup appropriate output
resolution.
1. On Windows Desktop, right-click and select
Properties from the menu
that appears.
2. Click the
Settings tab in the window that follows.
3. Drag the
Resolution slider and select a compatible resolution according to
"Supported PC (D-Sub/DVI) input signal resolutions" on page 48. If your
PC supports it, select 1360 × 768 as the output resolution for the best
result.
4. Click
OK to save the setting and close the window.
5. Switch the PC video output from monitor to the TV.
6. Press
INPUT and select the PC input.
Resolution
Horizontal
Frequency
(KHz)
Vertical
Frequency
(Hz)
Dot Clock
Frequency
(MHz)
Note
720 × 480i 15.735 60i 27 SDTV 480i
720 × 480p 31.47 60p 74.25 EDTV 480p
720 × 576i 15.625 50i 27 EDTV 576i
720 × 576p 31.25 50p 74.25 EDTV 576p
1280 × 720p 45 60p 74.25
HDTV720p
1280 × 720p 37.5 50p 74.25
1920 × 1080i 28.13 50i 74.25
HDTV1080i
1920 × 1080i 33.75 60i 74.25
V32B_V37B_EN.book Page 49 Wednesday, January 23, 2008 10:55 AM
