Inspection
1.1 Inspection
Before storing or installing the RSi GX, thoroughly inspect the device for possible shipping
damage. Upon receipt:
•
Remove the starter from its package and inspect exterior for shipping damage. If damage
is apparent, notify the shipping agent and your sales representative.
•
Open the enclosure and inspect the starter for any apparent damage or foreign objects.
Ensure that all of the mounting hardware and terminal connection hardware are properly
seated, securely fastened, and undamaged.
•
Ensure all connections and wires are secured.
•
Read the technical data label affixed to the starter and ensure that the correct horsepower
and input voltage for the application has been purchased.
•
If you will store the drive after receipt, place it in its original packaging and store in a
clean, dry place free from direct sunlight or corrosive fumes, where the ambient
temperature is not less than -20°C (-4°F) or greater than +65°C (+149°F).
•
Depending on the type of unit you have purchased, check that you have received all the
necessary parts. The delivery package should include the unit itself, this manual and a
Quick Start Guide. The Quick Start Guide gives a summary of the installation
instructions. It is not meant to be a substitute for the User Manual, rather it is meant to be
a supplement to the manual.
Interpreting Model Numbers
1.2 Model Numbers
The model number of the RSi GX drive appears on the shipping carton label and on the
technical data label affixed to the model. Read the technical data label affixed to the drive
and ensure that the correct horsepower and input voltage for the application has been
purchased. The numbering system for a Benshaw RSi GX drive is shown below.
5
1 - INTRODUCTION
Benshaw Drive
Applicable constant torque motor capacity
For example, 005 = 5HP
Series name of drive
Input voltage
2 = 230V, three-phase
4 = 460V, three-phase
Enclosure Type
B = NEMA 1 / I 31P
B
2
GX
005
RSi
Figure 1: RSi GX Drive Model Numbers
