Navigating codes in a group
When moving fromF1toF15inFunction group 1
4.2.3
Parameter Setting
•
Changing parameter values in Drive group
When changing ACC time from 5.0 sec to 16.0 sec.
39
4 - Operation
1
In F 1, continue pressing the Up (p) key until F15 is displayed.
2
Moving to F15 has been complete.
z Note: The same applies to Function group 2 and I/O group.
z Note: Some codes will be skipped in the middle of increment (p)/decrement (q) for code
change. That is because it is programmed that some codes are intentionally left blank for future use
or the codes user does not use are invisible.
For example, when F24 [High/low frequency limit select] is set to “O (No) ”, F25 [High frequency
limit] and F26 [Low frequency limit] are not displayed during code change. But When F24 is set to
“1(Yes)”, F25 and F26 will appear on the display.
F1
F15
1
In the first code “0.00”, press the Up (p) key once to go to the second
code.
2
ACC [Accel time] is displayed.
Press the Ent key () once.
3
Preset value is 5.0, and the cursor is in the digit 0.
Press the Left (t) key once to move the cursor to the left.
4
The digit 5 in 5.0 is active. Then press the Up (p) key once.
5
The value is increased to 6.0.
Press the Left (t) key to move the cursor to the left.
6
0.60 is displayed. The first 0 in 0.60 is active.
Press the Up (p) key once.
7
16.0 is set: Press the Ent () key once.
16.0 is blinking:
Press the Ent () key once again to return to the parameter name.
8
ACC is displayed. Accel time is changed from 5.0 to 16.0 sec.
z Note: In step 7, pressing the Left (t) or Right (u) key while 16.0 is blinking will disable the
setting.
z Note: Pressing the Left (t)/ Right (u) /Up (p) /Down (q) key while cursor is blinking will
cancel the parameter value change. Pressing the Enter key () in this status will enter the value into
memory.
0.00
ACC
ACC
5.0
5.0
6.0
06.0
16.0
