BENSHAW RSi GX Series User Manual

5.3 Function Group 2 [FU2]
51
5 - Parameter List
Code
[FU2]
Parameter Name Setting Range
Factory
Default
Adj.
during
run
Page
H0 Jump Code 1-95 1 Yes 83
H1 Fault History 1
- nOn - 84
H2 Fault History 2
H3 Fault History 3
H4 Fault History 4
H5 Fault History 5
H6 Reset Fault History
0 (No)
1 (Yes)
0
(No)
Yes 84
H7 Dwell Frequency 0.1 - 400 [Hz] 5.00 [Hz] No 84
H8 Dwell Time 0-10 [sec] 0.0 [sec] No 84
H10 Skip Frequency Select
0 (No)
1 (Yes)
0 (No) No 85
H11
1
Skip Frequency 1 Low
0.1 - 400 [Hz]
10.00 [Hz]
No 85
H12 Skip Frequency 1 High 15.00 [Hz]
H13 Skip Frequency 2 Low 20.00 [Hz]
H14 Skip Frequency 2 High 25.00 [Hz]
H15 Skip frequency low limit 3 30.00 [Hz]
H16 Skip frequency high limit 3 35.00 [Hz]
H17 S-Curve accel/decel start side 1~100 [%] 40 85
H18 S-Curve accel/decel end side 1~100 [%] 40 85
H19
Input/Output Phase Loss
Protection
0 (Disabled)
1 (Output phase
protection
2 (Input phase
protection)
3 (Input/Output
phase protection)
0
(Disabled)
Yes 86
H20 Power ON Start Select
0 (No)
1 (Yes)
0 (No) Yes 87
H21 Restart after Fault Reset Select
0 (No)
1 (Yes)
0 (No) Yes 87
H22
2
Speed Search Select
0000-1111 (bit
set)
Bit 0: during
Accel
Bit 1: after fault
reset
Bit 2: after instant
power failure
restart
Bit 3: when H20
is set to 1 (Yes)
0000 Yes 88
