BENSHAW RSi GX Series User Manual

Technical Data
2.1 Technical Data
1) Indicates the maximum applicable motor capacity when using a 4-pole motor.
2) Rated capacity is based on 220V for 200V class and 440V for 400V class.
3) Refer to when Carrier frequency setting (H39) is above 3kHz.
4) Max frequency setting range is extended to 300Hz when H40 (Control mode select) is
set to 3 (SVC).
5) Maximum output voltage cannot be higher than the input voltage. It can be
programmable below input voltage.
10
2 - TECHNICAL SPECIFICATIONS
Drive Type (RSixxxGX-2)
001 002 003 005
Motor
Rating
1
HP
1235
KW
0.75 1.5 2.2 3.7
Output
Ratings
Capacity[kVA]
2
1.9 3.0 4.5 6.1
FLA [A]
3
5 8 12 16
Max. Frequency 400 [Hz]
4
Max. Voltage
3f 200 - 230V
5
Input
Ratings
Rated Voltage
3f 200 - 230 VAC (+10%, -15%)
Rated Frequency 50 - 60 [Hz] (±5%)
Cooling Method Forced Cooling
Weight [kg]
0.77 1.12 1.84 1.89
230V Class (1.0 - 5.0HP)
Drive Type (RSixxxGX-4)
001 002 003 005
Motor
Rating
1
HP
1235
KW
0.75 1.5 2.2 3.7
Output
Ratings
Capacity[kVA]
2
1.9 3.0 4.5 6.1
FLA [A]
3
2.5 4 6 8
Max. Frequency 400 [Hz]
4
Max. Voltage 3f 380 - 480V
5
Input
Ratings
Rated Voltage 3f 380 - 480 VAC (+10%, -15%)
Rated Frequency 50 - 60 [Hz] (±5%)
Cooling Method Forced Cooling
Weight [kg]
0.77 1.12 1.84 1.89
400V Class (1.0 - 5.0HP)
