BENSHAW RSi GX Series User Manual

5.2 Function Group 1 [FU1]
49
5 - Parameter List
Code
[FU1]
Parameter Name Setting Range
Factory
Default
Adj. during
run
Page
F0 Jump Code 1-60 1 Yes 65
F1 Run Prevention
0 (Fwd/Rev Run
Disable)
1(ForwardRun
Disable)
2 (Reverse Run
Disable)
0
None
No 65
F2 Acceleration Pattern
0 (Linear)
1 (S-Curve)
0
Linear
No
66
F3 Deceleration Pattern
0 (Linear)
1 (S-Curve)
0
Linear
No
F4 Stop Mode Select
0 (Decel to Stop)
1 (DC-brake to Stop)
2 (Free-run to Stop)
0
Decel to Stop
No 67
F8 DC Brake Start Frequency 0.1-60 [Hz] 5.00 [Hz] No 68
F9 DC Brake Wait Time 0-60 [sec] 0.1 [sec] No 68
F10 DC Brake Voltage 0-200 [%] 50 [%] No 68
F11 DC Brake Time 0-60 [sec] 1.0 [sec] No 69
F12 DC Brake Start Voltage 0-200 [%] 50 [%] No 69
F13 DC Brake Start Time 0-60 [sec] 0.0 [sec] No 70
F14 DC Pulse at Start 0-60 [sec] 1.0 [sec] No 70
F20 Jog Frequency 0-400 [Hz] 10.00 [Hz] Yes 71
F21
2
Maximum Frequency 40-400 [Hz] 60.00 [Hz] No 71
F22 Base Frequency 30-400 [Hz] 60.00 [Hz] No 72
F23 Starting Frequency 0-10 [Hz] 0.50 No 72
F24 Frequency Limit Selection
0 (No)
1 (Yes)
0 (No) No 72
F25
3
High Limit Frequency 0.1-400 [Hz] 60.00 [Hz] No 73
F26 Low Limit Frequency 0.1-400 [Hz] 0.50 [Hz] No 73
F27 Torque Boost Select
0 (Manual)
1 (Auto)
0 (Manual) No 74
F28 Torque Boost in Forward
0-15 [%]
2.0% No 75
F29 Torque Boost in Reverse 2.0% No 75
F30 V/F Pattern
0 (Linear)
1 (Square)
2 (User V/F)
0
(Linear)
No 75
