BENSHAW RSi GX Series User Manual

50
5 - Parameter List
Code
[FU1]
Parameter Name Setting Range
Factory
Default
Adj. during
run
Page
F31
4
User V/F Frequency 1 0-400 [Hz] 15.00 [Hz] No
76
F32 User V/F Voltage 1 0-100 [%] 25 [%] No
F33 User V/F Frequency 2 0-400 [Hz] 30.00 [Hz] No
F34 User V/F Voltage 2 0-100 [%] 50 [%] No
F35 User V/F Frequency 3 0-400 [Hz] 45.00 [Hz] No
F36 User V/F Voltage 3 0-100 [%] 75 [%] No
F37 User V/F Frequency 4 0-400 [Hz] 60.00 [Hz] No
F38 User V/F Voltage 4 0-100 [%] 100 [%] No
F39 Output Voltage Adjustment 40-110 [%] 100 [%] No 77
F40 Energy Save Level 0-30 [%] 0 [%] Yes 78
F50 Electronic Thermal Selection
0 (No)
1 (Yes)
0 (No) Yes 78
F51
1
Electronic Thermal Level for 1
minute
50-200 [%]
150 [%] Yes 79
F52
Electronic Thermal Level for
continuous
100 [%] Yes 79
F53
Electronic Thermal
Characteristic selection (Motor
Type)
0 (Self-cool)
1 (Forced-cool)
0
Self-cool
Yes 80
F54 Overload Warning Level 30-150 [%] 150 [%] Yes 80
F55 Overload Warning Hold Time 0-30 [sec] 10 [sec] Yes 81
F56 Overload Trip Select
0 (No)
1 (Yes)
1 (Yes) Yes 81
F57 Overload Trip Level 30-200 [%] 180 [%] Yes 81
F58 Overload Trip Time 0-60 [sec] 60 [sec] Yes 82
F59 Stall Prevention Mode Select
000-111 (bit set)
Bit 0: during Accel.
Bit 1: during steady
speed
Bit 2: during decel
000 No 82
F60 Stall Prevention Level 30-150 [%] 150 [%] No 83
