Braking Resistor
9.1 Short Circuit Fuse / Braking Resistor
Use class H or K5 UL Listed Input Fuse or a UL listed breaker only. See the table below
for the required voltage and current rating of fuses and breakers. Recommended suppliers
for input fuses are Bussman or Ferraz Shawmut.
158
9 - Options
Input Voltage Motor [HP]
100% Braking 150% Braking
[W] [W]* [W] [W]*
200V
Class
1.0 200 100 150 150
2.0 100 200 60 300
3.0 60 300 50 400
5.0 40 500 33 600
400V
Class
1.0 900 100 600 150
2.0 450 200 300 300
3.0 300 300 200 400
5.0 200 500 130 600
* The wattage is based on Enable duty (%ED) 5% with continuous braking time 15 sec.
