BENSHAW RSi GX Series User Manual

Basic Wiring Diagram
3.4 Basic Wiring Diagram
23
3 - RECEIVING AND INSTALLATION
DB Resistor
B1
R
S
T
G
P1
24
P2
P3
P4
P5
P6
P7
P8
CM
ModBus-RTU
Speed Signal Input
Note:
Control Circuit Terminals
Main Circuit Terminals
Common for
VR,V1, I
Speed signal input:
0-20mA
Speed signal input:
-0-10V
Power supply for
speed signal:
10V
Potentiometer
Sheild
Sheild
Forward Run/Stop
24V Output
Output Frequency Meter
(0-10V pulse)
Common for AM
Fault Output Relay
lless than AC250V, 1A
lless than DC30V, 1A
lless than DC24V, 50mA
Factory setting ‘Run’
Reverse Run/Stop
Emergency Stop
Trip Reset
Jog
Multi-function 1
Multi-function 2
Multi-function 3
Common Terminal
Factory Setting:
‘Speed-L’
‘Speed-M’
‘Speed-H’
VR
V1
I
CM
B2
Motor
U
V
W
MO
MG
S+
S-
3B
3C
3A
AM
CM
AM
+
}
Control
Circuit
+
RSi GX
