52
5 - Parameter List
Code
[FU2]
Parameter Name Setting Range
Factory
Default
Adj.
during
run
Page
H23
Current Limit Level during
Speed Search
80-200 [%] 100 [%] Yes 90
H24 P Gain during Speed Search 0-9999 100 Yes
90
H25 I Gain during Speed Search 0-9999 200 Yes
H26
Number of Auto Restart
Attempt
0-10 0 Yes 91
H27 Auto Restart Time 0-60 [sec] 1.0 [sec] Yes 91
H30 Rated Motor Selection 0.2-7.5 7.5
1
No 92
H31 Number of Motor Poles 2-12 4 No 92
H32 Rated Slip Frequency 0-10 [Hz] 2.33
2
[Hz] No 92
H33 Motor Rated Current 0.5-50 [A] 26.3 [A] No 92
H34 No Load Motor Current 0.1-20 [A] 11 [A] No 93
H36 Motor Efficiency 50-100 [%] 87 [%] No 93
H37 Load Inertia Rate 0-2 0 No 94
H39 Carrier Frequency Select 1-15 [kHz] 3 [kHz] Yes 77
H40 Control Mode Select
0 (V/F)
1 (Slip Comp.)
2 (PID Feedback)
3 (SVC)
0 (V/F) No 95
H41 Auto Tuning 0-1 0 No 96
H42 Stator Resistance (Rs) 0-14 [W] - No 96
H44 Leakage inductance (Ls) 0-300.0 [mH] - No 97
H45
1
P Gain for PID Control 0-32767 1000 Yes 97
H46 I Gain for PID Control 0-32767 100 Yes 97
H50
2
PID Feedback Select 0-1 0 No 98
H51 P Gain for PID Controller 0-999.9 [%] 300.0 [%] Yes 98
H52 I Gain for PID Controller 0.1-32.0 [sec] 1.0 [sec] Yes 98
H53 D Gain for PID Controller 0-30.0 [sec] 0.0 [sec] Yes 98
H54 F Gain for PID Controller 0-999.9 [%] 0.0 [%] Yes 99
H55 PID Output Frequency Limit 0.1-400 [Hz] 60.00 [Hz] Yes 99
H60 Self-Diagnostic Select 0-3 0 No 100
H70
Frequency Reference for
Accel/Decel
0-1 0 No 101
H71 Accel/Decel Time Scale 0-2 1 Yes 102
H72 Power on Display 0-13 0 Yes 102
H73 Monitoring Item Select
0-Output Voltage
1-Output Power
2-Torque
0 Yes 103
H74 Gain for Motor RPM Display 1-1000 [%] 100 [%] Yes 103
H75
DB Resistor Operating Rate
Limit Select
0-1 1 Yes 103
