BENSHAW RSi GX Series User Manual

139
7 - Remote Communication
Address
Code Parameter Initial Value Max. Min.
16 bit 10 bit
A348 41800 H72 PowerOn disp 0 13 0
A349 41801 H73 User disp 0 2 0
A34A 41802 H74 RPM factor 100 1000 1
A34B 41803 H75 DB mode 1 1 0
A34C 41804 H76 DB %ED 10 30 0
A34D 41805 H77 FAN control 0 1 0
A34E 41806 H78 FAN Trip 0 1 0
A34F 41807 H79 S/W Version 100 0
A351 41809 H81 2nd Acc Time 50 60000 0
A352 41810 H82 2nd Dec Time 100 6000 0
A353 41811 H83 2nd BaseFreq 6000 MaxFreq 3000
A354
41812 H84 2nd V/F 0 2 0
A355
41813 H85 2nd F-Boost 50 150 0
A356
41814 H86 2nd R-boost 50 150 0
A357
41815 H87 2nd Stall 150 150 30
A358
41816 H88 2nd ETH 1min 150 200 H89
A359
41817 H89 2nd ETH cont 100 H88 50
A35A
41818 H90 2nd R-Curr 263 500 10
A35B
41819 H91 Para Read 0 1 0
A35C
41820 H92 Para Write 0 1 0
A35D
41821 H93 Para Init 0 5 0
A35E
41822 H94 Password Set 0 65535 0
A35F
41823 H95 Para. Lock 0 65535 0
Function Group 2 (H)
Address
Code Parameter Initial Value Max. Min.
16 bit 10 bit
A401 41985 I1 VR filter 10 9999 0
A402 41986 I2 VR volt x1 0 ViXmax[0] 0
A403 41987 I3 VR freq y1 0 MaxFreq 0
A404 41988 I4 VR volt x2 1000 1000 ViXmin[0]
A405 41989 I5 VR freq y2 6000 MaxFreq 0
A406 41990 I6 V1 filter 10 9999 0
A407 41991 I7 V1 volt x1 0 ViXmax[1] 0
A408 41992 I8 V1 freq y1 0 MaxFreq 0
A409 41993 I9 V1 volt x2 1000 1000 ViXmin[1]
A40A 41994 I10 V1 freq y2 6000 MaxFreq 0
A40B 41995 I11 I filter 10 9999 0
A40C 41996 I12 I curr x1 400 ViXmax[2] 0
A40D 41997 I13 I freq y1 0 MaxFreq 0
I/O Group (I)
