drv2: Drive Mode 2
Range: 0 - 2 (Default:1)
Description: <Active condition>
Option-Inverter Exchange is activated and drv2 and Frq2 in Drive group is
displayed when drv and Frq are set to “RS485” and one of the
multi-function input terminals is set to 22.
When the defined terminal is turned ON, setting values in drv2 and Frq2 are
applied without changing any parameters. However, change to the drive
mode and frequency mode is not available while this terminal is ON.
•
Run/Stop via Run/Stop key on the keypad.
•
Only displayed when one of the multi-function input terminals 1-8
[I17-I24] is set to "22".
•
Select the one terminal among P1-P8 to use this function.
Display:
Function:
0 Operation via Run/Stop key on the keypad.
1 FX: Forward/Run command, RX: Reverse/Run command
2 FX: Run/Stop command, RX: Forward/Reverse command
z Note: 1 and 2 are Operation via Terminal (see I17 - I24, and Frq2).
Frq2: Frequency Setting Method 2
Range: 0 - 6 (Default: 0)
Description: <Active condition>
Option-Inverter Exchange is activated and drv2 and Frq2 in Drive group is
displayed when drv and Frq are set to "RS485” and one of the
multi-function input terminals is set to “22”.
When the defined terminal is turned ON, setting values in drv2 and Frq2 are
applied without changing any parameters. However, change to the drive
mode and frequency mode is not available while this terminal is ON.
•
Only displayed when one of the multi-function input terminals 1-8
[I17-I24] is set to "22".
•
Select the one terminal among P1-P8 to use this function.
64
6 - Parameter Descriptions
