CARE OF YOUR MACHINE
Cleaning the Hook Race and Feed Dog
WARNING:
Turn the power switch off and unplug the machin before
cleaning.
The machine must only be disassembled as described in
this section.
CAUTION:
Do not store the machine in a high-humidity area, near a
heat radiator, or in direct sunlight.
Installing the Bobbin Holder
Insert the bobbin holder so that the knob fits next to
the stopper
in the hook race.
Insert the bobbin.
Attach the stitch plate with the setscrews . After clean-
ing the machine, make sure the needle and presser foot
are attached.
Bobbin holder
Stopper
Knob
Screwdriver
Setscrews
Press the needle stop up/down button to raise the needle. Turn
off the power switch.
Remove the needle and presser foot.
Remove the setscrew out of the left side from the stitch
plate
. Use theT screwdriver supplied with the machine.
Remove the stitch plate
.
Remove the bobbin. Lift up the bobbin holder and
remove it.
Clean the bobbin holder with a lint brush .
Clean the feed dog , thread cutter mechanism and
hook race
with the lint brush.
Clean the center of the hook race with a dry cloth.
Screwdriver
Setscrews
Stitch plate
Lint brush
Thread cutter mechanism
Bobbin holder
Feed dog
Hook race
(You may also use a vacuum cleaner.).
* The machine does not require oiling.
PLEASE NOTE:
Clean the outside of the machine with a soft cloth and
soap.
After cleaning the machine, make sure the needle and
presser foot are attached.
