Density Meter LB 444 SECTION 2. SYSTEM DESCRIPTION
24
Live Display
Start measurement
A measurement can be started from any menu item by pressing the <
run
> but-
ton (exception: Service menu). Then the measured values are displayed con-
tinuously in the selected unit for the selected product.
RUN
appears on the dis-
play.
With <
+
> and <
-
> you can cycle through the displays below.
Menu sk2: Live Display
In this menu the results are displayed if
RUN
appears on the display; otherwise
the values of the last measurement.
With <
+
> and <
-
> you can cycle through the displays below.
Density display:
The actual density can be displayed in the defaulted range, e.g. 1.234 g/cm³.
I-mean
The average countrate is displayed. The entered basic time constant is used as
time constant.
I-actual
The actual countrate is displayed. The entered basic time constant is used as
time constant.
HV auto:
Display of adjusted high voltage (HV).
Mass flow display
The actual concentration [%] and the mass flow [kg/h] are displayed in the de-
faulted range.
Integr. M=[t]
The integrated mass is displayed.
Flow =[m³/h]
The actual volume flow is displayed.
Stop measurement by pressing <
run
> again.
Select the measuring product in the menu sk1: Parameter.
