Berthold LB 444 - Calibration and Connection of Pt 100 Resistance Thermometer; Basic Settings

Density Meter LB 444 SECTION 5. GETTING STARTED
43
Calibration and Connection of Pt 100 Resistance Thermometer
The Pt 100 input is calibrated in the factory. A new calibration is required only
when the detector boards or the detector microprocessor are replaced.
1. Apply 100 Ω (with lowest tolerance) to Pt 100 input at the detector (terminals
3 and 4, Figure 21).
2. Press <
enter
> until the menu Service Menu/Mass Flow is displayed.
3. Select Service menu with <
sk1
>.
4. Press <
more
> twice and then select Pt 100 calibration with <
sk2
>.
5. Press <
sk2
> (2
nd
softkey) and <
clear
> at the same time. When the display
„Pt 100 calibration running...“ appears, press <
more
>.
6. Then connect resistance thermometer to detector, terminal 3 and 4, (see
Figure 21).
Basic Settings
These steps describe the procedure for taking the system into operation
and changing the system setting.
Note:
To enter numbers, select the entry position with <
←←←
←←←←←←
←←←
> and the number
you want with <
^^^
>. Confirm your selection or new entry with <
enter
>.
Press <
run
> to return to the display mode directly any time (except in the Serv-
ice menu).
1. Select menu General Data / Operating Mode via the key <
more
>.
1.1 Select General Data menu with <
sk1
> and with <
more
> call the parame-
ters sequentially.
• Enter password and unlock or lock the system with <
enter
>
• Check date & time and correct it, if necessary
• Check instrument version (e.g. LB 444, version 1.0)
• Select language
• Print Parameter, only if needed
Factory Setting, only if needed
• Software Functions and System Configuration)
Return to the menu group with <
done
>.
1.2 Select Operating Mode menu with <
sk2
> and the operating modes with
<
^^^
>.
•
Select Config Instrument with <
^^^
> and confirm with <
enter
>:
Density measurement with or without TC (Pt 100 or current input)
Mass flow measurement with or without TC (Pt 100)
•
Select radiation measure to irradiate the product. Select backscat-
ter measure if source and detector are installed parallel.
•
Define Error mode
•
Select parameters for RS232 interface
Return to the menu group with <
done
>.
