Beta ALP 200 - Front Brake Lever and Gas Control; Lh Switch; Rh Switch

2
OPERATION
19
EN
LH SWITCH
The dip and service switch is located on
the left side of the handlebar and is com-
posed as follows:
1 Horn button;
2 Dip switch
( high beam ; low beam)
3 High beam switch;
4 Turn signal light switch: Shifting lever
left or right activates the left or right indi-
cators. When released, the lever returns
to the central position. Press it to turn the
indicators off.
1
2
3
4
RH SWITCH
The start/stop switch is located on the
right side of the handlebars and is made
up as follows:
1 Starter button. Push the button until the
engine starts. Do not press the button 1
while the engine is running.
2 Shut-down: press the button until the
engine stops.
FRONT BRAKE LEVER AND GAS
CONTROL
The front brake lever A and the gas throt-
tle B are located on the right side of the
handlebar.
2
1
A
B
