4
CHECKS AND MAINTENANCE
47
EN
BRAKE DISC THICKNESS
CONTROL
Periodically verify disc condition. In case
signs of damage , veins, or deformations
are present, proceed with replacement.
Verify disc thickness. The minimum thick-
ness is engraved on the disc.
Once the limit is in proximity or has been
reached, proceed with brake disc replace-
ment.
For replacement, contact an authorised
Betamotor after-sales service centre.
CHECK AND ADJUSTMENT
OF STEERING PLAY
Periodically check the play in the steering
sleeve by moving the fork back and forth
as shown in the figure. Whenever you feel
play, adjust as described below:
- Loosen the screws 1
- Loosen nut 2
- Reduce the play by turning ring 3
Tighten the bolts to the prescribed torque
values.
1
2
3
40Nm
20Nm
