HEADLIGHT
Keep the headlight glass clean at all times
(see page 57).
Periodically check the correct angle of the
light beam (chapter 3).
REPLACING THE HEADLIGHT
BULBS
Remove the fixing screws and move for-
ward the lamp holder front cowl.
Carefully remove lamp 1 complete with
the lamp holder.
Replace the day/position 1 light by remov-
ing the lamp from the lamp holder and
replacing it with a new one (page 16
for the type of lamp).
Replace the high/low beam light as fol-
lows:
-disconnect connector 2;
-remove the rubber cap 3;
-unhook spring 4 and remove the lamp..
Replace with a new lamp (page 16
for lamp info).
Warning: do not touch the bulb so as to
avoid compromising the efficiency of the
lamp.
To refit, follow the procedure above but in
reverse order.
NOTE: When you have completed this
operation, check the direction of the beam
(page 36).
1
2
3
4
