31
SET NORM PC SAMPLING RATE
Factory set for 15 (seconds), the Sampling Rate can be set to val-
ues of 2 , 15 , 30 , or 60 (seconds), or 0,5 , 1,5 , or 3 M (2, 5 , or 10
FT).
To access the Set Sampling Rate screen while viewing the SET 2
screen, press/release the A (Advance/Left) button 8 times (< 2 sec-
onds each time).
• The graphics SR and SEC (or M or FT) appear with the setting
flashing (Fig. 30/31).
> Press/release the S (Select/Right) button to advance the setting
1 selection at a time, or press/hold the button to scroll through
the settings at a rate of 4 per second.
> Press/release the A (Advance/Left) button to accept the setting
and advance to Set Audible Alarm, or press/hold Both buttons
for 2 seconds to revert to the SET 2 screen.
• Operation reverts to NORM SURF MAIN in 2 minutes if no
button is pressed.
Fig. 31 - SET SAMPLING RATE
(by DEPTH)
Fig. 30 - SET SAMPLING RATE
(by TIME)
