Parts List and Drawings
Section 13: Parts List and Drawings
Table 19. Parts List
Item Qty Description Item Qty Description Item Qty Description
1 4 Screw 29 1 Worm wheel 57 4 Column
2 1
Terminal board cover 30 1 Planicentric assembly
58 1 Torque plate
3 1
* O-ring 31 1 Guide bush
59 2 Screw
4 1 Terminals label 32 1
*
O-ring 60 1
*
O-ring
5 4 Screw 33 1 Thrust block 61 1 Torque/Position
assembly
6 1 Circlip 34 1
*
O-ring 62 1
*
O-ring
7 2 Screw 35 4 Washer 63 4 Screw
8 1
Power terminals cover 36 4 Stud bolt
64 1 Data plate
9 1 Terminal board 37 4 Nut 65 1 Power card
10 1 I/O card 38 2 Mechanical stops nut 66 4 Column
11 1
*
O-ring 39 2 Mechanical stops 67 1 Potentiometer card
12 1 Cover housing 40 2 Seal washer 68 1 Processor card
13 1 Earth stud 41 2 Nut 69 1 Display plate
14 2 Earth stud nut 42 1 Pin 70 1
*
O-ring
15 2 Washer 43 1 Bearing 71 4 Column
16 1 Earth stud indication
plate
44 1 Support ange 72 1 Local interface
assembly
17 2 Screw 45 1 Circlip 73 4 Screw
18 1 Electric motor 46 2 Oil plug Optional
19 1
*
Seal ring 47 1 Handwheel stop
screw
A 1 Bus interface card
20 1 Bearing 48 1 Pin B 1 Battery group
21 1
*
O-ring 49 1 Worm gear assembly
22 1 Screw 50 1 Circlip
23 1 Housing 51 1 Handwheel ring
24 2
*
Pin 52 1 Handwheel slide ring
25 1 Bearing 53* 1
*
O-ring
26 1 Double wheel 1
st
stage
54 1 Handwheel retaining
ring
27 1 Wheel 2
nd
stage 55 1 Handwheel
28 3 Screw 56 1 Hand grip
NOTE:
* Recommended spare parts
