September 2021
Installation, Operation and Maintenance Manual
VCIOM-01249-EN Rev. 0
32
Operating the F01-2000
Section 5: Operating the F01-2000
Figure 28
OPTION D1
OPTION D2
OPTION E1
OPTION E2
5.9 Optional Modules
Additional modules can be plugged in the base card of the F01-2000 to provide the
following functions:
5.9.1 Fieldbus Interface for Remote Control via Fieldbus
This card allows to connect the F01-2000 to FIELDBUS.
The following bus interface cards are available:
• Probus DPVO
• Probus DPV1 with or without redundancy
• Foundation Fieldbus
• LonWorks
• Modbus RTU
A Hardware alarm is generated if the F01-2000 was set to be equipped with bus card, but
the card is damaged or missing. A BUS REPORT is also present in the list of reports if the
card is present (see Section 6). See the specic manuals for instructions and the setting of
the above modules.
