BIFFI F01-2000 User Manual

September 2021
Installation, Operation and Maintenance Manual
VCIOM-01249-EN Rev. 0
31Operating the F01-2000
Section 5: Operating the F01-2000
If the upper line of the display shows “ALARM OFF”, remove the alarm before going ahead
(see Section 12.10).
If the upper line of the display shows “WARNING OFF”, a warning condition is present.
You can go ahead since the F01-2000 is working well, but some datum is not according to
the congured parameters (see Section 12.10).
If the upper line of the display shows “INT OFF”, an Interlock input is active. If the upper line
of the display shows “ESD ON OFF”, the ESD input is active.
If the following message appears, the base card is F01-2000 v4 type, but the actuator is
equipped with an F01-2000 v0 series terminal board. This may happen if the F01-2000 v4
base card was supplied as a spare card, to replace the base card of the F01-2000 v0
series (see the previous revision of instruction manuals relevant to the F01-2000 and its
optional modules).
Bif Italia
F01-2000 v4 otb
Do not operate the actuator without rst checking that the conguration is according to
the required application by using the “VIEW and SET-UP” features (see Section 6/10).
Set torque limits, position limits and close direction by means of the “stroke limits routine”
of the “actuator set-up” menu (see Section 9).
When the stroke limits and the congurations are correct, bring the 3-position selector to
LOCAL and drive the actuator to open or closed position (see Section 5.4).
