September 2021
Installation, Operation and Maintenance Manual
VCIOM-01249-EN Rev. 0
79View Routines
Section 10: View Routines
Section 10: View Routines
10.1 Actuator Set-Up
The above menu allows to view the present actuator conguration. No change can be
made to the present data. The following data can be viewed (see Table 12).
Routine Parameters
Stroke limits Close direction (CW, CCW), close limit type (torque or position),
open limit type (torque or position)
Torque set-up Closing torque limit %, opening torque limit %
ESD controls ESD action, signal type, ESD priority
Remote controls Control type
Locals controls Control type, LED’s color
Output relays Monitor relay conditions, ASi conditions, contact action
Positioner * Dead band, motion inhibit time, polarity, %min, %max
(%min and %max are present only if “position request R%” is from
4 - 20 mA input)
Fail-safe * Action, delay
Out 4 - 20 mA * Output signal (position or torque), polarity
Interlock Signal type in OP, signal type in CL
2-speed timer Close direction: status, start, stop, on time, off time
Open direction: status, start, stop, on time, off time
Bus *
Node address, terminations, etc. depending on eldbus type
Miscellaneous Time and date, torque mode, lithium battery, torque bypass %,
valve jammed time
Table 12.
NOTE:
The routines with * can only be viewed if the relevant electronic cards are present. If the bus interface is
LonWorks, routine “BUS” changes to “FDI control”. Detailed descriptions of the above routines and their
parameters can be found in Section 9.
View procedure
• Move the local selector to OFF and then simultaneously press OPEN and STOP.
Select the language according to the instructions (see “Entering the view mode”).
When the message displayed is “VIEW MODE OK?” press YES. Press YES to select
the actuator set-up menu.
• Press NO to scroll the list of available routines and press YES to select.
• Press YES to answer at the prompt “view” or “next” and to see the data.
