Sept
embe
r 2021
Installation, Operation and Maintenance Manual
VCIOM-01249-EN Re
v
. 0
109
Par
ts List and Drawing
s
Section 13: Par
ts List and Drawings
Figure 72
F01-2000 - T
orque/Position Assembly
T
able 22.
Parts List
Item
Qty
Description
61.1
1
Gear c
ov
er
61.2
5
Screw
61.3
1
Gea
r
61.4
1
Gea
r
61.5
1
Screw
61.6
1
Gea
r
61.7
8
Screw
61.8
1
Gea
r
61.9
1
T
orque f
ork
61.10
1
T
orque sha
ft
61.11
2
Pot
entiome
ter
61.12
1
Position sh
aft
61.13
1
T
orque/Po
sition plat
e
61.3
61.4
61.2
61.5
61.1
61.6
61.7
61.9
61.10
61.8
61.11
61.12
61.13
