Big Backyard F23210 - Rock Wall Assembly

 16 support@cedarsummitplay.com
Step 2: Rock Wall Assembly
A:Lay2(0349)RockRailsdown,sidebysidewithanglededgesfacingdown.(g.2.1)
B:Place(1779)CEAccessBoardonthebottomofeach(0349)RockRailasshowning.2.1.Makesure(1779)
CEAccessBoardisushtotheoutsideandbottomedgesofeach(0349).Attachusing4(S2)#8x1-1/2”Wood
Screws.
C:7-3/4”downfromthetopofboth(0349)RockRailsplace1(1777)CERockBoardB,makingsurethesidesare
ushtotheoutsideedgesofeach(0349)RockRail.Attachusing4(S2)#8x1-1/2”WoodScrews.(g.2.1)
D:Inbetweenthe(1779)CEAccessBoardand(1777)CERockBoardBstagger2(1778)and2(1777)CERock
BoardsA&Busing4(S2)#8x1-1/2”WoodScrewsperboard.Placingthemasshowning.2.1,thiswillprevent
rocksfromformingastraightline.Makesuretheboardsareevenlyspacedanddonotexceed2-3/8”between
boards.
E: Place1rockoneach(1777)and(1778)
CERockBoardA&B(g.2.2)andattach
using1(PB2)1/4x1-1/4”PanBolt(withlock
washer,atwasherandbarrelnut)and1
(S10)#8x1”PanScrewperrock.TheScrew
mustbeintheholedirectlyunderthePan
Bolt,itwillstoptherockfromspinning.(g.
2.3)
Note: Gaps between boards 2-1/4”,
not to exceed 2-3/8”
Note: The holes in the rock boards
must orient to the top of the boards.
7-3/4”
Approx
Fig. 2.1
S2
1779
0349
1778
1777 1777
1777
1778
Fig. 2.2
Fig. 2.3
1 x CE Access Board 1 x 6 x 17”
3 x CE Rock Board B 1 x 6 x 17”
2 x CE Rock Board A 1 x 6 x 17”
2 x Rock Rail 2 x 3 x 51”
24 x #8 x 1-1/2” Wood Screw
5 x #8 x 1” Pan Screw
5 x 1/4 x 1-1/4 Pan Bolt
(1/4” lock washer, 3/16” at washer & 1/4” barrel nut)
S2
0349
1778
1777
1779
3/16”Flat
Washer
1/4”Lock
Washer
1/4”Barrel
Nut
Rock
5 x Rocks (3 green/2 yellow)
S10
S10
Wood Parts
Hardware
Other Parts
PB2
PB2
