Step 12: Attach Gusset to Front Frame Assembly
A:Makesuretheassemblyissquarebeforeproceeding.
B:Fromtheinsideoftheassembly,attach(0312)Gussetushtotheoutsideedgeof(1931)PostontheSwing
Wallusing2(S4)#8x3”WoodScrews.Theotherendofthegussetshouldbetightagainst(1908)FrontFloor.
(g.12.1and12.2)
C:Attachtheotherendof(0312)Gussetto(1908)FrontFloorwith1(S3)#8x2-1/2”WoodScrewand1(S4)
#8x3”WoodScrewasshowning.12.2.
Wood Parts
Hardware
1 x #8 x 2-1/2” Wood Screw
3 x #8 x 3” Wood Screw
S4
S3
1x Gusset 2 x 3 x 16”
0312
1908
0312
Flushtoedge
S3
S4
S4
S4
0312
1931
Fig. 12.2
Fig. 12.1
