Step 4: Swing End Assembly
A:Attach2(1863)SWPoststo(1856)SWUprightusing2(G4)5/16x4”HexBolts(withlockwasher,at
washerandt-nut).(g.4.1)
B:Attach(1862)SWSupporttoboth(1863)SWPostsand(1856)SWUprightusing3(G5)5/16x4-1/2”Hex
Bolts(withlockwasher,atwasherandt-nut).(g.4.1)
Wood Parts
Hardware
2 x 5/16 x 4” Hex Bolt
(5/16” lock washer, 5/16” at washer, 5/16” t-nut)
3 x 5/16 x 4-1/2” Hex Bolt
(5/16” lock washer, 5/16” at washer, 5/16” t-nut)
G4
G5
2 x SW Post 2 x 4 x 86-11/16”
1 x SW Support 5/4 x 4 x 46-1/2”
1 x SW Upright 2 x 4 x 48-5/16”
1862
1863
1856
5/16”Flat
Washer
5/16”Lock
Washer
5/16”
T-Nut
Fig. 4.1
1863
1862
1856
G4
G5
1863
G5
5/16”Flat
Washer
5/16”Lock
Washer
5/16”
T-Nut
