Big Backyard F23210 - Attach Swing Assembly to Fort

 50 support@cedarsummitplay.com
Hardware
Step 31: Attach Swing Assembly to Fort
A:AttachSwingAssemblyfromStep5to(2035)SWMountwith1(G5)5/16x4-1/2”HexBolt(withlockwasher,
atwasherandt-nut)and1(G8)5/16x2”HexBolt(with2atwashersand1locknut)asshowning.31.1.
1 x 5/16 x 2” Hex Bolt
(5/16” at washer x 2, 5/16” lock nut)
1 x 5/16 x 4-1/2” Hex Bolt
(5/16” at washer, 5/16” lock washer, 5/16” t-nut)
G5
G8
2035
Fig. 31.1
5/16”Flat
Washer
5/16”Lock
Washer
5/16”
T-Nut
G5
G8
5/16”Flat
Washer
5/16”Flat
Washer
5/16”
LockNut
