Step 8: Connect Monkey Bar Assemblies
1-1/4”
MKBracket
Hardware
2 x 5/16 x 3” Hex Bolt
(5/16” lock washer, 5/16” at washer, 5/16” t-nut)
8 x #12 x 1” Pan Screws
S6
1367
1367
Fig. 8.1
Fig. 8.2
5/16”Flat
Washer
5/16”Lock
Washer
5/16”
T-Nut
S6
G10
G10
x4
S6
Other Parts
2 x MK Bracket
A:UsingaMKBracketconnectboth(1943)MKRailLongand(1565)MKRailShorttoeach(1367)PostMKwith
1(G10)5/16x3”HexBolt(withlockwasher,atwasherandt-nut)perbracketandMKBrackettotherailsusing2
(S6)#12x1”PanScrewsperrailasshowning.8.1and8.2.
B:AttachMKBrackettoboth(1367)PostMKswith2(S6)#12x1”PanScrewsperbracket.(g.8.2)
Note: Pre-drill all holes using a 1/8” drill bit before installing the pan screws.
Thisend
connects
toPost
Thisendconnects
toMKMount
1565
1943
G10
