1 inch = 25.4mm
SOLO)WAVE DESIGN HARDWARE
For example:
BOLT LENGTH 4½ (4.5) inches long
114mm long
1 inch = 25.4mm
25.4mm
4.5 inches x
DIAMETER CONVERSION
LENGTH CONVERSION
=
BOLT DIAMETER 5/16 (0.31) inches 0.31 inches
x 25.4mm = 8mm
For example:
HARDWARE LENGTH CHART
inches vs millimetres
6 152
5½ 140
5 127
4½
114
4 102
3½ 89
3 76
2½ 64
2 51
1½ 38 1¼ 32
1-
1/8
29
1 25.4
7/8 22 3/4 19 1/2 12.7
1/4" (6mm) Flat Washer
1/4" (6mm) Lock Washer
1/4"(0.25) = 6mm Hex Bolt
1/4" (6mm) T-Nut
5/16"(.31) = 8mm Lag Screw
5/16" (8mm) Flat Washer
1/4"(0.25) = 6mm Lag Screw
1/4" (6mm) Flat Washer
5/16" (8mm) Flat Washer
5/16" (8mm) Lock Washer
5/16"(.31) = 8mm Hex Bolt
5/16" (8mm) T-Nut
3/8"(.38) = 9.5mm Lag Screw
3/8" (9.5mm) Flat Washer
