Step 30: Attach Stool Seat to Fort
A:AttachtheStoolSeatAssemblyto(2036)CafeGroundusing2(G2)5/16x1”HexBolt(withlockwasher,at
washerandt-nut)perSeatAssembly.(g.30.1and30.2)
Hardware
4 x 5/16 x 1” Hex Bolt
(5/16” lock washer, 5/16” at washer, 5/16” t-nut)
G2
2036
Fig. 30.1
G2
G2
Fig. 30.2
G2
5/16”Flat
Washer
5/16”Lock
Washer
5/16”
T-Nut
2036
PartsRemovedforClarity
